1/2″x16 BSF HSS GT STR. FLUTE TAP SET
Rp1.026.000
Sets of Three
1 each, taper, second and plug lead.
Out of stock
SKU : SHR0851660D
Sets of Three
1 each, taper, second and plug lead.
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (mm) : 89.0
Shank Diameter (mm) : 9.0
Size – Pitch : 1/2″ x 16
Square A/F : 7.1
Thread Length (mm) : 29.0
UNSPSC Code : 27112806
Weight per set : 182g
| Weight | 1 kg |
|---|
