1/4″x18 NPTx1.1/2″ O/D HSS DIE
Rp2.942.000
NPTâ(National Pipe Taper) HSS Ground Thread Dies
For use in diestocks to produce external screw threads.
Out of stock
SKU : SHR0869430K
NPTâ(National Pipe Taper) HSS Ground Thread Dies
For use in diestocks to produce external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 1 1/2″
Size – Pitch : 1/4″ x 18
Thickness (inch) : 1/2″
UNSPSC Code : 27112805
Weight each : 88 g
| Weight | 1 kg |
|---|
