3/8″x20 BSF HSS GT STR. FLUTE TAPER TAP
BSF (British Standard Fine) HSS Ground Thread Taps
IS0 529 – Straight Flute Individual Sizes
Out of stock
SKU : SHR0851640A
BSF (British Standard Fine) HSS Ground Thread Taps
IS0 529 – Straight Flute Individual Sizes
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length : 80.0
Shank Diameter : 10.0
Size – Pitch : 3/8″ x 20
Thread Length : 24.0
UNSPSC Code : 27112806
Weight each : 38g
| Weight | 1 kg |
|---|
