M10x1.5 YELLOW SP/PT 371 HSS-EV OX TAP
HSS-EV ‘Yellow Ring’ Taps
Spiral Point/Gun Nose –
HSS-EV Oxidised Finish
For through holes.
Taper lead to DIN form B.
(3.5 x P to 5.5 x P).
Tapping tolerance to 6H.
Suitable for the following Material Groups;
1.1
Mild soft steel & free machining non-alloy low carbon steel.
1.2
Non-alloy case hardening, structural & low to medium carbon steel.
1.3
Non-alloy, plain and medium carbon steel and castings
Out of stock
SKU : SWT1850030Y
HSS-EV ‘Yellow Ring’ Taps
Spiral Point/Gun Nose –
HSS-EV Oxidised Finish
For through holes.
Taper lead to DIN form B.
(3.5 x P to 5.5 x P).
Tapping tolerance to 6H.
Suitable for the following Material Groups;
1.1
Mild soft steel & free machining non-alloy low carbon steel.
1.2
Non-alloy case hardening, structural & low to medium carbon steel.
1.3
Non-alloy, plain and medium carbon steel and castings
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length : 100.0
Shank Diameter (mm) : 10.0
Size x Pitch (mm) : M10.0 x 1.50
Square A/F : 8.0
Thread Length (mm) : 22.0
UNSPSC Code : 27112806
Weight each : 55g
| Weight | 1 kg |
|---|
