M4x0.7 YELLOW SP/FL 371 HSS-EV OX TAP
HSS-EV ‘Yellow Ring’ Taps
Spiral Flute – HSS-EV Oxidised Finish
For blind holes.
Taper lead to DIN form C (3 x P).
Tapping tolerance:
Spiral flute to 6H.
Suitable for the following Material Groups;
1.1
Mild soft steel & free machining non-alloy low carbon steel.
1.2
Non-alloy case hardening, structural & low to medium carbon steel.
1.3
Non-alloy, plain and medium carbon steel and castings
Out of stock
SKU : SWT1850515Y
HSS-EV ‘Yellow Ring’ Taps
Spiral Flute – HSS-EV Oxidised Finish
For blind holes.
Taper lead to DIN form C (3 x P).
Tapping tolerance:
Spiral flute to 6H.
Suitable for the following Material Groups;
1.1
Mild soft steel & free machining non-alloy low carbon steel.
1.2
Non-alloy case hardening, structural & low to medium carbon steel.
1.3
Non-alloy, plain and medium carbon steel and castings
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 63.0
Shank Diameter (mm) : 4.5
Size x Pitch (mm) : M4.0 x 0.70
Square A/F : 3.4
Thread Length (mm) : 7.0
UNSPSC Code : 27112806
Weight each : 8g
| Weight | 1 kg |
|---|
